Message Archival
info

Information

The Message Archival feature is an add-on (paid). To know more, talk to your Customer Success Manager or raise a support ticket

Overview

Message archival is the process of storing any communication sent to customers for later access. Retaining these customer messages is important for multiple reasons, including:

  • Regulatory compliance: Various regulatory bodies globally, depending on the region and/or industry (especially in the BFSI sector), mandate businesses to store any "electronic communication" with the customer. While certain rules recommend storing customer communications, others necessitate businesses to do so. In a few cases, the retention rules also describe the type of communication that should be retained, for instance, either storing all messages (including promotional ones) or storing at least transactional messages for a defined period.
    Some rules and guidelines by the respective regions are as follows:
    Country or Region Rule or Guideline
    US FINRA Rule 2210
    SEC Rule 17a-4
    GLBA Rule for Financial Information Privacy
    FRCP Rule 26
    Canada IDA 29.7
    EU MiFID II
    UK Durable Medium
    India Digital Lending Guidelines
    The retention period varies for each rule: for instance, SEC Rule 17a-4 has a default six-year retention period whereas GLBA rule for Financial Information Privacy has a default retention of seven years.
  • Customer experience: Your customers may be contacting your support touch-points, enquiring about a message they have received. To serve these customers better, you need to empower your teams with information on all transactional and/or promotional messages sent to customers. Your customer service teams can then respond to a customer query and/or complaint by reviewing the personalized message sent to the customer.

    Combining this with the message sent/delivery events (using MoEngage S3 Exports or Streams) can give your teams a 360-degree view of messages received or those that remained undelivered because of various reasons such as the Email box being full or mobile number being unavailable and so on. This 360-degree view of communication sent by you (brand) to your customers helps customer service teams get a holistic context, thereby reducing the turnaround time (TAT) and the cost to serve and, more importantly, improving the overall customer experience.

  • Audit: Message archival is a powerful tool for reviewing the content sent to customers. If ever there is a case where a customer complains or disputes a message they received, you can use these archived files to identify the relevance of the claim.

Recommendation: Retain a copy of the customer messages for at least two to six months, if not more, for the aforementioned reasons.

Message Archival in MoEngage

MoEngage offers the Message Archival feature where businesses can choose to keep a copy of actual notification content sent to customers. This feature helps you stay compliant with regulations, solves your audit needs, and enables you to cater to your customers better. The feature is available for the Email, SMS, and Push channels.

Other benefits of this feature include:

  • Indefinite storage: You can choose to store these messages in MoEngage for a month or as long as you need.
  • Automated archival: Once the feature is enabled, it would automatically archive customer messages across all vendors/platforms for the specified channels.
  • Secure storage: MoEngage ensures the message files are kept in a safe manner, including keeping the messages encrypted.
  • UI-based access: Each message can be accessed for a user and event on the MoEngage dashboard.
  • Option to download each file: Easily download the message files to keep a local copy.
  • Fetch message files (optional): MoEngage allows you to pull these messages to your file store. All the files have a unique identifier to ensure the files can be traced back to the campaign/alert.
Channels Message Archival supported?
Push Yes
SMS Yes
Email Yes
WhatsApp No
In-App No
OSM No
Connectors No

View a Message Copy on the Dashboard

You can view the copy of an archived message (Email or SMS ) sent to the customer on the MoEngage dashboard. To do so:

  • Go to the Activity Info tab in the User Profile of the customer for whom you wish to look up the communication sent.
  • Under User Activity > Events, you will find the list of events associated with the user.
  • Message copies are available under the Email Sent, SMS Sent, Notification Received Android, Notification Sent iOS, and Notification Received Web events.
Email SMS Push

To view the copy of the email sent to a customer:

  1. Navigate to the User Profile of the user.
  2. Click the Activity Info tab.
  3. Look for the email sent to the customer under the Email Sent event associated with the campaign you are looking for.
  4. Click View sent message to view the communication sent to the customer.
  5. Click Download at the top-right corner to download the EML file corresponding to the email sent.

Note:

  • The links in the email copy are added only for illustration and may not work.
  • Templates beyond 250 KB will not be archived.
  • Email attachments are not archived.

2023-06-05_15-17-10

info

Information

Message Archival is not supported in MoEngage when PII Tokenized Sending is enabled.

Store Your Files

You have the following options to store your files:

  • Store them in MoEngage S3 bucket
  • Store them in your S3 bucket

Storing your files in the MoEngage S3 bucket can be beneficial if you want to view the archived files on the MoEngage UI. If you store the files only in your own S3 bucket, MoEngage will need Read Access to display those archived files on the UI.

info

Information

If you choose a configuration, you cannot change it later. If you decide to store the message files in your S3 bucket, you cannot change this configuration and store them with MoEngage.

If you want to store these files with the MoEngage S3 bucket, then MoEngage will create a bucket for you and store your messages securely.

Storing files in your S3 Bucket:

  1. Share the name of the S3 bucket where you want to store your data and provide the read and write access to MoEngage.
  2. You also need to provide the ARN URL for your bucket. For more information, refer to Set Up the ARN URL.
  3. MoEngage requires the folder name for storing your files.
  4. MoEngage requires the name of a different file path if you want to change from the default file path.

Set Up the ARN URL

Even if you have an S3 bucket already, we still recommend creating a new bucket specifically for MoEngage so you can limit permissions.

  1. To create a bucket for your app, open the S3 console and follow the instructions to Sign in or Create an Account with AWS.
  2. After you sign in, select S3 from the Storage & Content Delivery category.
  3. Select Create Bucket on the next screen and you will be prompted to create your bucket and select a region.
  4. Navigate to the Policies tab in the navigation bar and select Get Started then Create Policy. This will allow you to add permissions for your user.
  5. Select Create Your Own Policy. This will give limited permissions so we only can access the bucket that you specify.
  6. When creating your own policy, specify a Policy Name of your choice and enter the following code into the Policy Document section. Be sure to replace the INSERTSID with your SID, INSERTPOLICYID with your policy ID, and INSERTBUCKETNAME with your bucket name.

    DC-01, DC-02, DC-03, and DC-04 DC-05 and DC-06
    {
        "Statement": [
            {
                "Effect": "Allow",
                "Principal": {
                    "AWS": [
                        "arn:aws:iam::612427630422:role/S3-EC2-InstanceRole",
                        "arn:aws:iam::612427630422:role/campaigns_archival_s3_export-role-e1qw8ulf"
                    ]
                },
                "Action": [
                    "s3:GetObject",
                    "s3:PutObject",
                    "s3:ListBucket",
                    "s3:GetLifecycleConfiguration"
                ],
                "Resource": [
                    "arn:aws:s3:::",   ### clinet bucket arn
                    "arn:aws:s3:::".   ### clinet bucket arn
                ]
            }
        ]
    }

Frequently Asked Questions

arrow_drop_down What is the file retention period, and for how long will these messages be visible on the dashboard?

The file retention period refers to the time duration for which these customer message files are stored with MoEngage. The default message file retention period is dependent on the file retention period of your S3 bucket.

These messages will be visible on the dashboard for 30 days by default. This time is dependent on the event retention period.

The message files are accessed on the MoEngage dashboard using events such as Email Sent, Notification Received Android, Notification Sent iOS, Notification Received Web, and SMS Sent. To access all the message files stored through the MoEngage dashboard, the event-retention period should be equal to or greater than the retention period of the message files. Alternatively, these message files can be stored for offline access, not through the MoEngage dashboard.

Note: Both the MoEngage event-retention period and message-file retention period can be set as per your needs.

arrow_drop_down How do I access or view my files if they are not visible on the dashboard?

If the event-retention period has expired for your files, you can fetch the files by using a query language and query the S3 where the files are stored.

arrow_drop_down What will happen if S3 is down while files are being written to it?

MoEngage supports two retries to combat this situation. The first retry of writing the files occurs one hour after the initial attempt. If S3 is still down, the second retry occurs four hours after the initial attempt.

If writing the files is unsuccessful even after two retrials, MoEngage stores the copies of these files internally for 30 days. You can raise a support ticket to get them written to your bucket manually.

arrow_drop_down Why are my files not being written in S3?

There may be multiple reasons for your files not being written in S3.

  • The read access for your bucket may be revoked for MoEngage.
  • The write access for your bucket may be revoked for MoEngage.
  • The folder where the files are stored may not be found.
  • S3 might be down for a longer period of time and both retries can also fail.
arrow_drop_down How can I enable the message archival feature, change the event retention period, or change the file retention period?

Contact your CSM or raise a support ticket.
